Aluminum Primary High Temperature Air Filter Commercial Air Pre Filter

    Buy cheap Aluminum Primary High Temperature Air Filter Commercial Air Pre Filter from wholesalers

    Buy cheap Aluminum Primary High Temperature Air Filter Commercial Air Pre Filter from wholesalers
    • Buy cheap Aluminum Primary High Temperature Air Filter Commercial Air Pre Filter from wholesalers

    Aluminum Primary High Temperature Air Filter Commercial Air Pre Filter

    Ask Lasest Price
    Brand Name : SFF
    Model Number : 001
    Price : 2-5USD
    Payment Terms : L/C, D/A, T/T, Western Union, MoneyGram
    Supply Ability : >10000
    Delivery Time : 7-15work days
    • Product Details
    • Company Profile

    Aluminum Primary High Temperature Air Filter Commercial Air Pre Filter

    air filter supplier high temperature resistant aluminum primary air filter


    Product Description


    Features

    Frame: Paper, Aluminum

    Media: Non-woven reinforced cotton &synthetic media

    Media support grid: welded steel wire, anti-corrosive

    Fire retardant grade: UL-2 listed. (UL 900)

    Humidity: <= 100% RH

    Recommended Max. Final Pressure drop: <=225 P



    Applications

    Pre filters for commercial & industrial AHU.



    Advantages



    Metal mesh support at downstream, with strengthening cross together

    "V" shape of stainless steel wire designed at the upstream, user can replace the material very easy ,the frame can be reused

    Filter media and frame bonded by adhesive, can ensure no bypass or leakage even under large air flow

    Hasp avaiable, if needed by installation type


    Model
    Outside Dimensions(mm)
    Rated air flow(m3/h)
    Initial resistance(Pa)
    Efficiency(class)
    Filter media
    295×295×10/20mm
    800m3/h
    25Pa
    40%

    weight
    G1

    G2

    G3
    Non-woven reinforced cotton & synthetic media
    12″×12″×1/2″/1″
    495×295×10/20mm
    1300m3/h
    25Pa
    20″×12″×1/2″/1″
    495×495×10/20mm
    2200m3/h
    25Pa
    20″×20″×1/2″/1″
    595×295×10/20mm
    1600m3/h
    25Pa
    24″×12″×1/2″/1″
    595×295×10/20mm
    1600m3/h
    25Pa
    24″×12″×1/2″/1″
    595×595×10/20mm
    1600m3/h
    25Pa
    24″×24″×1/2″/1″

    Product Description

    Features
    Frame: Paper, Aluminum
    Media: Non-woven reinforced cotton &synthetic media
    Fire retardant grade: UL-2 listed. (UL 900)
    Humidity: <= 100% RH
    Recommended Max. Final Pressure drop: <= 225 Pa
    Applications
    Pre filters for commercial & industrial AHU.
    Advantages
    7 pleats/feet, 40% higher than normal product
    With holding frame, very strong structure
    Customer can replace the material very easy by themselves, the holder and frame can be recycled
    Washable, Can be reused when necessary

    Aluminum Primary High Temperature Air Filter Commercial Air Pre FilterAluminum Primary High Temperature Air Filter Commercial Air Pre Filter
